Slon YS868i USB RS232 1D/2D Desktop Automatic High Speed Omnidirectional Directional Barcode Scanner for Supermarket Store POS WindowsXP, Windows7,Windows8,Windows10,ISO

Slon YS868i USB RS232 1D/2D Desktop Automatic High Speed Omnidirectional Directional Barcode Scanner for Supermarket Store POS WindowsXP, Windows7,Windows8,Windows10,ISO

Be the first to review this product

● Plug and play, not need any driver, easy to operate

● Blue & Red LED indicator,double buzzer to adapt to various nosy environments

● Using the latest high performance hard decoding chip

● Supports auto-sleep and quickly wake-up functions

● The apperance is novelcan easily embedded in various devices

Availability: In stock

$109.00

Manufacturer: SLon

We will send this product in 2 days. Read more...

Call us now for more info about our products.

Return purchased items and get all your money back.

Buy this product and earn 10 special loyalty points!

Customization Services

We can provide product development, OEM, personalized customization services.

There are too many spare parts models, if you don't find what you want here, please contact us.

Details

Details

Slon YS868i Desktop Automatic High Speed Omnidirectional Directional USB 1D Barcode Scanner RS232 20 Scan Lines

Suit for all POS systems and machine.
Blue and Red LED indicator,double buzzer.
Plug and play, not need any driver, easy to operate.
Anti-Scraping protection glass large window design.
The appearance is novel, fashionable and founder.
Supports auto-sleep and quickly wake-up functions.
20 scan lines with 5 directions at rate of 1650 scans per second.
Compatibility WindowsXP, Windows7,Windows8,Windows10,ISO etc.

Application area:

Mainly used in large supermarkets, shopping malls,speciality stores,etc.(pharmacy, clothing stores, tobacco, hotels)

OPERATIONAL PARAMETER

Light Source 650nm visible laser diode (VLD)

Depth of Field(DOF): 4mil:10-50mm,5mil:0-90mm, 7.5mil:0-170mm,10mil:0-220mm,13mil:0-240mm

,20mil:0-300mm Note: DOF May vary depending on environment condition and barcode quality

Scan Lines: 20

Scan Rate: 1650 times per second

Minimum Resolution 0.1mm(4mil)@ Code39, PCS=90%

Print Contrast: More than 30% @ UPC/EAN 100%

Visual Indicator: Two color LED （Blue ,Red）

Beeper Operation Programmable tone & Volume

PHYSICAL CHARACTERISTICS

Dimension H x W x L: 150mm*75mm*150 mm

Weight 490g (without cable), lightweight to save shipping cost.

Material ABS + PC

Cable Standard 1.8M straight

POWER PARAMETER

Input Voltage 5VDC±10%

Working corrent 220mA

SAFETY REGULATORY

Laser Class CE EN55022 B, FCC Part 15 Class B, VCCI, BSM I

EMC CDRH Class IIa, IEC 60825-1 Class 1

ENVIRONMENTAL PARAMETER

Operating Temperature 0°C to 50°C

Storage Temperature -20°C to 60°C

Working Humidity 5% to95% relative humidity, non-condensing

Light Levels 0~4,000Lux（Fluorescence），0~100,000Lux（sunlight）

Drop Durability Designed to withstand 1M drops

DECODE CAPABILITY

UPC/EAN/JAN,UPC-A & UPC-E,EAN-8 & EAN-13, JAN-8 &JAN-13, ISBN/ISSN, Code 39 (with full ASCII), Codabar (NW7), Code 128 & EAN 128,Code 93,Interleaved 2 of 5 (ITF),Addendum 2 of 5, IATA Code,MSI/Plessy, China Postal Code,Code 32 (Italian Pharmacode),RSS 14,RSS Limited, RSS Expanded
